Description

price includes domestic USA freight**********************

The Nano motorcycle lift designed and produced in LV8 is able to best concentrate design and elevated performances.

Thanks to its being only 7,5 cm (3”) high when closed and its retractable ramp it is the lowest and most safe motorcycle lift in the world.

The lowest motorcycle lift in the world

The LV8 NANO motorcycle lift, thanks to its being only 7,5 cm (3”) high when closed and its retractable ramp, is the lowest and most safe motorcycle lift in the world. It is the best performing solution for state-of-the-art motorcycle workshops, able to optimize space and time increasing productivity.

Electro-hydraulic unit in external cabinet

The LV8 NANO motorcycle lift is supplied with the electro-hydraulic unit in metal external cabinet with “dead man” controls 24V and interlocked safety switch. This control unit can be perfectly integrated into our workshop furnishings.

Certified hydraulic safety system

The hydraulic system with double cylinder equipped with a self- lubricating system for the seals allows infinite height adjustments of the LV8 NANO motorcycle lift ensuring the best reliability both when going up and down, without having to manually insert or release mechanical levers.

Retractable run-up ramp

The motorcycle lift LV8 NANO is equipped with retractable run-up ramp to ensure a safe, ergonomic workstation, free of any obstacle on the floor, speeding up the maintenance operations on the vehicle. When the lift goes up the ramp runs smoothly and silently and disappears inside the basement.

Platform with removable gate and set-up for fitting accessories

The platform of the LV8 NANO motorcycle lift is provided with removable gate to facilitate the demounting of motorbikes rear wheels and it is equipped with set-up for fitting wheel clamps, front extensions, ratchet tie downs and antiskid central covers.

Pads in self-lubricating plastic materials

The platform of the LV8 NANO motorcycle lift is equipped with pads in self-lubricating plastic materials and self-lubricating bushes on all joint linchpins to make all up/down operations silent, safe and performing, reducing the need of maintenance over time

SPECS

“Dead man” controls 24V

Electrical safety device

Capacity 400 kg

Power supply 220V 1ph

Suitable for recessed installation or on the floor

Equipped with pre-mounted hydraulic pipes lenght 2 mt enabling the installation of the control unit

Base and lever extended

Front output pipes

Technical features
Capacity 400 kg
Max. height 1030 mm
Min. height 75 mm
Platform width 650 mm
Platform length 2000 mm
Ramp width 466 mm
Ramp length 298 mm
Standard equipment
2 side tools holders

Retractable run-up ramp

Front safety bar

Pipe protection cover
